| Enclosure Type | bass reflex |
| Transducer Complement | 3-way |
| Bass Driver | 6.5"(165mm) black woven Kevlar cone |
| Midrange Driver | 2"(50mm) soft dome |
| Treble Driver | 30x60mm AMT |
| AV Shield | No |
| Sensitivity (2.83V @ 1M) | 87dB |
| Recommended Amplifier Power | 25-120W |
| Peak SPL | 105dB |
| Nominal Impedance | 8 Compatible |
| Minimum Impedance | 4 |
| Frequency Response ( /-3dB) | 54Hz ~ 22kHz |
| Bass Extension (-6dB) | 48Hz |
| Crossover Frequency | 1.4kHz,3.9kHz |
| Dimensions (HxWxD) | 455 x 250 x (340 10)mm |
| Net Weight | 13.4kg/pcs |
