RX V4A SPECIFICATIONS:
| Amplifier Section | Channels | 5.2 | |
|---|---|---|---|
| Rated Output Power (20Hz-20kHz, 2ch driven) | 80 W (6 ohms, 0.06% THD) | ||
| High Slew Rate Amplifier | Yes | ||
| Surround Sound Processing | Cinema DSP | Yes | |
| DSP Programs | 17 | ||
| Dialog Level Adjustment | Yes | ||
| Virtual Presence Speaker | Yes | ||
| Virtual Surround Back Speaker | N/A | ||
| Dialogue Lift | N/A | ||
| SILENT Cinema / Virtual Cinema DSP | Yes | ||
| Dolby Atmos | N/A | ||
| Dolby Atmos Height Virtualization | N/A | ||
| Dolby TrueHD | Yes | ||
| Dolby Digital Plus | Yes | ||
| Dolby Surround | N/A | ||
| DTS:X | N/A | ||
| DTS-HD Master Audio | Yes | ||
| Audio Features | File Format | MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 192 kHz / 24-bit, WAV / AIFF: up to 192 kHz / 32-bit, DSD: up to 11.2 MHz | |
| Pure Direct | Yes | ||
| Compressed Music Enhancer | Yes | ||
| YPAO Multipoint Measurement | N/A | ||
| YPAO Volume | Yes | ||
| Adaptive DRC (Dynamic Range Control) | Yes | ||
| Initial Volume and Maximum Volume Setting | Yes | ||
| A.R.T. Wedge | N/A | ||
| Bi-amp Capability | Yes | ||
| Audio Delay | Yes (0-500 ms) | ||
| DA Converter | 384 kHz / 32-bit BB PCM5101A | ||
| Video Features | HDMI eARC | Yes | |
| HDMI Audio Return Channel | Yes | ||
| HDMI Pass-through | 4K120AB*, 8K60B* and 4K60 (*via future update) | ||
| HDMI Upscaling | Yes up to 4K | ||
| Dolby Vision | Yes | ||
| HDR 10 | Yes (via future update) | ||
| VRR/ALLM/QMS/QFT | Yes (via future update) | ||
| Connectivity | MusicCast Surround | Yes | |
| Wi-Fi | Yes (2.4 / 5 GHz) | ||
| AirPlay 2 | Yes | ||
| Bluetooth | Yes (SBC / AAC) | ||
| Phono Input | N/A | ||
| Extensive Connections | HDMI Input/Output | 4 / 1 (HDR / Dolby Vision / HLG and BT.2020-compatible) | |
| HDMI CEC | Yes | ||
| USB Input | Yes | ||
| Network Port | Yes | ||
| Front AV Input | USB | ||
| Digital Audio Input / Output: Optical | 1 / 0 | ||
| Digital Audio Input / Output: Coaxial | 1 / 0 | ||
| Analog Audio Input / Output | 3 / 0 | ||
| Preout | 0.2-ch | ||
| Headphone Output | 1 | ||
| Tuner Section | FM / AM Tuner | Yes | |
| User Interface | On-Screen Display | Graphical User Interface | |
| SCENE | Yes (4 sets) | ||
| App Control | Yes (iPhone / iPad / Android phone / tablet) | ||
| Web Browser Control | N/A | ||
| Remote Control Unit | Yes | ||
| Zone Control | Zone 2 Audio Output | N/A | |
| Powered Zone | N/A | ||
| 12V Trigger Output | N/A | ||
| Remote (IR) Input/Output | N/A | ||
| Party Mode | N/A | ||
| General | Standby Power Consumption (IR only) | 0.1 W | |
| Auto Power Standby | Yes | ||
| ECO Mode | Yes | ||
| Dimensions (W x H x D) | 17-1/8" x 6-3/4" x 14-7/8" D (with antenna up:17-1/8" x 9-5/8" x 14-7/8") | ||
| Weight | 19.4 lbs. | ||
NS 777 SPECIFICATIONS
| Type | 3-Way, 4-Speaker Bass-Reflex Floor-Standing Speaker System | |
|---|---|---|
| Woofers | Dual 20cm PMD cone | |
| MidRange Driver | 13cm cone with Waveguide horn | |
| Tweeter | 2.5cm aluminium dome with Waveguide horn | |
| Frequency Response | 30 Hz-35 kHz | |
| Nominal Input Power | 100 W | |
| Maximum Input Power | 250 W | |
| Sensitivity | 89 dB/2.83 V/1 m | |
| Crossover Frequencies | 1 kHz/4 kHz | |
| Impedance | 6 ohms | |
| Dimensions (W x H x D) | 276 x 1,100 x 390 mm | |
| Weight | 24.4 kg/unit | |
| Type | 2-Way Bass-ReflexSpeaker System | |
|---|---|---|
| Woofers | 13cm PMD cone | |
| Tweeter | 2.5cm aluminum dome with Waveguide horn | |
| Frequency Response | 60 Hz-35 kHz | |
| Nominal Input Power | 60 W | |
| Maximum Input Power | 150 W | |
| Sensitivity | 87 dB/2.83 V/1 m | |
| Crossover Frequencies | 3 kHz | |
| Impedance | 6 ohms | |
| Dimensions (W x H x D) | 200 x 320 x 213 mm | |
| Weight | 5.5 kg/unit | |
| Type | 2-Way Acoustic Suspension Center Speaker System | |
|---|---|---|
| Woofers | Dual 13cm PMD cone | |
| Tweeter | 2.5cm aluminium dome with Waveguide horn | |
| Frequency Response | 55 Hz-35 kHz | |
| Nominal Input Power | 100 W | |
| Maximum Input Power | 250 W | |
| Sensitivity | 89 dB/2.83 V/1 m | |
| Crossover Frequencies | 3 kHz | |
| Impedance | 6 ohms | |
| Dimensions (W x H x D) | 514 x 190 x 213 mm | |
| Weight | 7.3 kg | |
SW 050
| Driver | 20 cm (8) cone | |
|---|---|---|
| Dynamic Power | 100 W (5 ohms) | |
| Output Power | 50 W (100 Hz, 5 ohms, 10% THD) | |
| Frequency Response | 28200 Hz | |
| Advanced YST | Yes | |
| Twisted Flare Port | Yes | |
| Dimensions (W x H x D) | 291 x 292 x 341 mm; 11-1/2 x 11-1/2 x 13-3/8 | |
| Weight | 8.5 kg; 18.7 lbs. | |
